Manitou MT-1840 Verreiker 03 +14

Manitou MT-1840

Manitou

The Manitou MT-1840 telehandler offers a lifting height of 18 metre and a capacity of 4 ton. Adapted with forks, winch, crane arm or other attachment it is a true multi tasker. Read more

Max. Capacity 4000 kg
Lifting Height 18000 mm
Drive Diesel
Transmission Torque convertor
More specifications

The Manitou MT-1840 telehandler offers a lifting height of 18 metre and a capacity of 4 ton. Adapted with forks, winch, crane arm or other attachment it is a true multi tasker.



The Manitou MT-1840 telehandler was specially designed for high rise work on construction sites and industrial sites. With a lifting capacity of 4.000 kg and a lifting height of 18 metres these machines offer an excellent working envelope.



Simplified usage

The commonality of design make the Manitou MT telehandlers easy to use and maintain. A spacious and comfortable design offer the operator a nice, rustic working environment for optimal productivity. With the unique, ergonomical Manitou JSM lever you have all functions in the palm of your hand.



The Easy Connect System allows depressurisation of the hydraulic attachment line without needing to turn off the engine.





High performance

A new generation Deutz Stage V engine offers an excellent performance. Combined with a choice in transmission that suits your needs (hydrostatic or torque convertor),  4 wheel drive, 4 wheel steering and an excellent stability the Manitou MT-1840 offers all you need for maximum productivity.





Versatility

Thanks to the unique Manitou attachment system, you can easily equip your telehandler with a wide range of attachments within a matter of seconds. Forks, buckets, crane jibs, winches, concrete mixers, etc. This is just a small list of all the available attachments for multiple applications.

Brand Manitou
Max. Capacity 4000 kg
Lifting Height 18000 mm
Model MT-1840 ST5
Drive Diesel
Transmission Torque convertor
Load center 500 mm
Truck weight 11.870 kg
Number of wheels, front / rear (x=driven) 2x / 2x
Width 2.42 m
Turning circle radius 3.94 m
Travel speed, with / without load 25 km/h
Engine, brand Deutz
Engine, type TCD 3.6 Stage V
Engine, output 75 kW
