The Manitou MT-1840 telehandler offers a lifting height of 18 metre and a capacity of 4 ton. Adapted with forks, winch, crane arm or other attachment it is a true multi tasker.
The Manitou MT-1840 telehandler was specially designed for high rise work on construction sites and industrial sites. With a lifting capacity of 4.000 kg and a lifting height of 18 metres these machines offer an excellent working envelope.
Simplified usage
The commonality of design make the Manitou MT telehandlers easy to use and maintain. A spacious and comfortable design offer the operator a nice, rustic working environment for optimal productivity. With the unique, ergonomical Manitou JSM lever you have all functions in the palm of your hand.
The Easy Connect System allows depressurisation of the hydraulic attachment line without needing to turn off the engine.
High performance
A new generation Deutz Stage V engine offers an excellent performance. Combined with a choice in transmission that suits your needs (hydrostatic or torque convertor), 4 wheel drive, 4 wheel steering and an excellent stability the Manitou MT-1840 offers all you need for maximum productivity.
Versatility
Thanks to the unique Manitou attachment system, you can easily equip your telehandler with a wide range of attachments within a matter of seconds. Forks, buckets, crane jibs, winches, concrete mixers, etc. This is just a small list of all the available attachments for multiple applications.
Brand | Manitou |
Max. Capacity | 4000 kg |
Lifting Height | 18000 mm |
Model | MT-1840 ST5 |
Drive | Diesel |
Transmission | Torque convertor |
Load center | 500 mm |
Truck weight | 11.870 kg |
Number of wheels, front / rear (x=driven) | 2x / 2x |
Width | 2.42 m |
Turning circle radius | 3.94 m |
Travel speed, with / without load | 25 km/h |
Engine, brand | Deutz |
Engine, type | TCD 3.6 Stage V |
Engine, output | 75 kW |
